Select a gooseneck specification
Engineered for Maximum Stability and Capacity
Our gooseneck roll-off trailers are built for operators who need serious capacity, confident towing, and rock-solid stability under load. With GVWR options from 14,000 lb up to 30,000 lb and dumpster lengths from 12’ to 20’, these trailers are designed for heavy commercial, industrial, and municipal work.
Each unit is built on a heavy-duty steel frame with Dexter tandem axles, 20-ply tires, electric drum brakes, dual deep-cycle batteries, and high-capacity Warrior winches (18,000 lb–25,000 lb depending on model). Dual lift cylinders and a proven tilt-frame design provide reliable loading and dumping performance, even with dense material and full-size containers.
Optional Honda GX390 gas power units, upgraded reeving systems, and hydraulic jacks are available on select models for operations that demand faster cycle times and maximum lifting power.
Gallery
Benefits
The gooseneck design improves weight distribution, towing stability, and maneuverability compared to traditional bumper pull trailers — ideal for higher GVWR and longer dumpster lengths.
Main frames are built from 4″ x 10″ rectangular tubing or large I-beam / C-channel combinations, paired with reinforced crossmembers and tilt frames to handle demanding commercial loads day after day.
Dexter tandem axle kits (single or dual wheel), 20-ply load range “J” tires, and oversized electric drum brakes are spec’d for serious duty cycles and heavier materials.
Dual Group 27 batteries, onboard 110V charger, wireless/cable remote controls, dual lift cylinders, DOT LED lighting, sealed wiring, and electric-hydraulic tarp systems with your logo all come standard.
Every trailer can be finished in your choice of Sherwin-Williams color code, with reflective tape, safety decals, and platform details tailored to your operation.
Gooseneck Trailer Features
| Feature | Specification | Notes |
|---|---|---|
| Main Frame | 4" x 10" Rectangular Tubing or 8" I-Beam + C-Channel (model dependent) | Heavy-duty steel construction |
| Tongue / Neck | 10" or 12" I-Beam Gooseneck | Improved towing stability and weight distribution |
| Axles | Dexter Tandem Axles (7k, 9k, 10k, 15k) | Single or dual wheel depending on GVWR |
| Brakes | Electric Drum Brakes | Oversized drums on higher GVWR models |
| Tires & Wheels | 17.5" 20-ply, Load Range J | Commercial-grade tires for heavy loads |
| Winch | Warrior 18,000–25,000 lb | Capacity varies by model |
| Lift Cylinders | Dual 3.5" or 4" Bore Cylinders | Up to 30k+ max rated lift |
| Power & Controls | Dual Group 27 Batteries, Onboard 110V Charger | Cable & wireless remote included |
| Lighting | All LED, DOT-Compliant | Sealed wiring harness & 7-way plug |
| Tarp System | Electric-Hydraulic Tarp System | Custom logo available |
| Finish | Sherwin-Williams Industrial Coating | Available in all SW color codes |
Available Gooseneck Models
| Model | GVWR | Dumpster Length | Axle / Wheel Setup |
|---|---|---|---|
| 14k Gooseneck – 12′ | 14,000 lbs | 12′ | 2 x 7k, Single Wheel |
| 14k Gooseneck – 14′ | 14,000 lbs | 14′ | 2 x 7k, Single Wheel |
| 18k Gooseneck – 12′ | 18,000 lbs | 12′ | 2 x 9k, Single Wheel |
| 18k Gooseneck – 14′ | 18,000 lbs | 14′ | 2 x 9k, Single Wheel |
| 18k Gooseneck – 16′ | 18,000 lbs | 16′ | 2 x 9k, Single Wheel |
| 20k Gooseneck – 16′ | 20,000 lbs | 16′ | 2 x 10k, Dual Wheel |
| 30k Gooseneck – 16′ | 30,000 lbs | 16′ | 2 x 15k, Dual Wheel |
| 30k Gooseneck – 20′ | 30,000 lbs | 20′ | 2 x 15k, Dual Wheel |
Typical Applications
- Dumpster rental & waste hauling
- Construction & demolition debris
- Industrial and municipal roll-off routes
- Roofing, restoration & disaster cleanup
- Material handling for yards and transfer stations
